About Illegal RGB Levels
Most video formats are recorded, edited, and transmitted in Y´C
B
C
R
(component) color
space. Although you may never intentionally convert your footage to RGB color space,
it is fairly certain that it will become RGB at some point—most likely during display on
a television or monitor. Video is almost always converted to RGB color space within
display devices.
When you work in Y´C
B
C
R
color space, levels are either described in their native color
space or they are referred to as RGB-equivalent values, meaning the values of your
Y´C
B
C
R
video signal when it is eventually converted to RGB.
Illegal RGB levels are generally caused when certain combinations of luma and chroma
levels (in Y´C
B
C
R
color space) are converted to RGB color space. Even if both luma and
chroma levels are legal in Y´C
B
C
R
color space, the combination of these two may cause
illegal RGB levels.
∏
Tip: The RGB Parade scope in the Video Scopes tab is useful for viewing RGB levels
when working in Y´C
B
C
R
color space. For more information, see “
Learning to Read the
RGB Parade Scope
” on page 518.
Legal RGB levels are usually defined as 0 percent to 100 percent, where 0 percent is the
lowest legal value and 100 percent is the highest. When Y´C
B
C
R
footage is converted to RGB,
RGB levels can be illegal in two ways: if they are below 0 percent or above 100 percent.
Note: If your video originated using a codec that is already in RGB color space (such as
the Animation codec), it is unlikely that the RGB levels are illegal.
